International Library of Technology · Scranton, International Textbook Co. · leaf 448
reliable. STYLES OF FUSE BOXES. 18. Tlie Westinghouse Fuse Box.—Fig. 19 shows aperspective view of aWestinghouse car fusebox and Figs. 20 and21 show how the re-movable block thattakes the fuse wire isconstructed. Fig. 20 shows thefuse box with the lidopen; a, a are the twocastings that receivethe… … Fig. 10. 16 ELECTRIC RAILWAYS. 25 the fuse will not set the wooden case on fire. Holes ^, e . , give the hot air and gases a chance to es-cape, so that when afuse bloAvs, the lid ofthe box may not beblown off. Holes k arefor the screws that holdthe fuse box up againstthe platform stem underthe car.…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
