International Library of Technology · Scranton, International Textbook Co. · leaf 483
circle bars roll as the truck rotates, thereby preservingthe position of the brake rigging. 25 ELECTRIC RAILWAYS. 51 66. Fig. 65 is a diagrammatic sketch of one-half the rig-ging used on a maximum-traction truck, where most of theweight is on the large wheels, so that most of the pressuremust be…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 483](https://img.insideoutlibrary.com/img/1024/ia-electricengineer04inte-483-254.webp)
