Electricians' operating and testing manual; (1910)
Horstmann, Henry C. [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] joint author · Chicago, F. H. Drake & co · leaf 339
Figure 200 dials also reads 87 the total reading being 8889 kilowatthours. In Figure 200 the readings are also given in kilo-watt hours. The pointer on the first dial at the right … Figure 201has not passed the 0 mark so this dial must be read9/10ths of a kilowatt hour or .9; the second dial reads5; the middle dial 6; the fourth dial 9 and the lastdial 1, making the total reading 1965.9 kilowatt hours.In Figure 201 the dial at the right indicates 9 kilo- 338 Operating and…
Electrical engineering · Electric testing
