ed in termsof a constant K^ and the deflection d. If the direction of the current changes, the polarity of bothcoils will change, and the deflection will still remain thesame. For this reason, as previously stated, the instrumentwas used for many years to measure alternating currents.At present,… … Fig. 44. — Electro-dynamometer. ELECTRO-MA G METISM 31 TJie Effect of an Iron Core in a Helix. Experiment 16. Pass a current of electricity of about 5 amperesthrough a helix, as in Fig. 40, so that it will just deflect a small compassneedle placed at some distance from it, say a foot. Introduce a…
