Gerard, Eric Mary, 1856-1916 · New York W.J. Johnston · leaf 108
A. I. E. E. Transactions, 1S92, p. 40.X Ibid., Part II, A. I. E. E. Transactions, 1892, p. 653. 92 HYSTERESIS—MOLECULAR MAGNETIC FRICTION. cive force. In the cycles of Figs. 31 to 33, the abscissae arenot the field intensities X, but the ampere-turns per centi-metre length of the magnetic circuit,… … Fig. 33.—Magnetic Cycles of Welded Steel at Different Degrees OF Hardness. as for instance in dynamo machinery—the hysteretic cyclechanges to the shape shown in Fig. 34, in which the straightdotted line represents the M. M.. F. required for the magnet-ization of the air-gap, and the hysteretic loop…
Electricity · Magnetism
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
