Electricity and magnetism : an elementary text-book, theoretical and practical (1920)
Glazebrook, Richard, Sir, 1854-1935 · Cambridge : The University press · leaf 217
uri*ent of 1 ampere flowing for onehour. It is thus 3600 coulombs. Accumulators usually contain a number of plates rangedside by side, the odd plates are connected together to form onepole of the cell, while the even plates connected together formthe other. The capacity of the cell depends on the… … Fig. 132. 132. Arrangement of Batteries in Series. Con-sider two batteries A, B (Fig. 133). Let Cj, Z^ be the copperand zinc plates of the one, G^, Z^ those of the second; E.^ andE^ being the electromotive forces. Connect together Z-^ and G^.Connect Cj and the junction of Z^ and G^ by two wires…
Electricity · Magnetism
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
