then E = E^^E^^E^^ 133. Arrangement of Batteries in Multiple Arc or Parallel. Consider nowtwo cells having the sameE.M.F., E. The potential dif-ference both between Cj andZ^, and between C^ and Z^, isE. If then (7i and (7, (Fig. 134)be connected by one wire toone pair of quadrants of… … Fig. 134. 182-133] THE ELECTRIC CURRENT 209 arc, and when the two have the same e.m.p. this is also theE.M.p. of the combination. If the two cells be not equal in e.m.f. the stronger cell willsend a current round the circuit and the problem of finding thepotential diiference between the plates is…
