Electricity and magnetism for advanced students (1920)

Starling, Sydney George, 1873- · London Longmans, Green · leaf 62

An illustration from Electricity and magnetism for advanced students, 1920, leaf 62
the magnetic lines of force are not so simple in shape as in the case ofa straight wire, but they may be found in a similar manner, and itwill be noticed that for a small region near the centre of the circle,the field is nearly uniform, that is, the lines are nearly parallel. Thefundamental…

Electricity · Magnetism

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
