The electric motor and the transmission of power (1906)
Houston, Edwin J. (Edwin James), 1847-1914, Kennelly, Arthur E. (Arthur Edwin), 1861-1939, joint author · New York : McGraw Pub. Co. · leaf 200
Fig. 49.—Skeleton of Motor Parts. at 3 and 2, respectively. The coils ofinsulated wire which surround them are inpractice wound on spools so that the entirecoil can be readily removed from the core.Such a coil is shown at -4, in Fig. 30. The 192 THE ELECTRIC MOTOR AND cast-iron base of the macliine… … Fig. 50.—Complete Motor of Type Shown in Fig. 49. In Fig. 49j a skeleton representation ofthe different parts of a particular form ofmotor, is shown in place. Here the arma-ture, with its commutator and pulley, ismounted between the pole pieces of theelectromagnet as shown. In this machine, THE…
Electric motors
