FiG. 95.—Field Ring with Poles and Bobbins in Place. nently excited by a continuous currentfrom a separate generator. The field ring-is 11 T in diameter, and revolves at 250revolutions per minute. The cover of thefield ring is shown in an inverted position 320 THE ELECTEIC MOTOR AND in Fig. 96. A,… … Fig. 96.—The Driver for the Field Ring. Since the field maf>;nets revolve aroundthe fixed armature, it is necessary tofirmly attach the field to the shaft. Thisis effected by means of the cover just de-scribed. A completed machine is repre-sented in position in Fig. 97. A vertical cross-section…
