81 THE ELECTRIC HAMMER. The second terminal of the coil is soldered to the metallic frame at any convenient point. … FIG. 32. PLAN OF CONNECTIONS op ELECTRIC HAMMER. To the frame a swinging arm is pivoted, the same pivot serving for it and for the contact plate. It is bent so as to pass back of the stem of the hammer, and has two striking pins extending from it. A pin attached to the hammer stem, strikes one of…
