les of most of our moderncommercial ammeters and voltmeters and is constructedon just the reverse principle of the Thomson type. The in-strument consists essentially of a coil of fine wire pivoted orsuspended in a powerful magnetic field. In the most sensitiveinstruments the coil is suspended by a… … Telescope Fig. 97. — DArsonval galvanometer. N and S, poles of fixed magnet. nometer which is convenient for use in the laboratory. A softiron core is supported rigidly between the poles in order toconcentrate the magnetic lines of force. The rotation of themoving coil of such a sensitive…
