and tenons. lOO ELEMENTARY CABINETWORK In striking the circles for the. corners, place athin block under the stationary leg of the compasses(Fig. 84). The corners should be smoothed with the chisel, using a shear-ing cut (Fig. 85).Before chiseling thecorners they may berounded by sawingwith a… … Fig. Marking the round corners shelf and ends, first draw light pencil lines acrossthe grain, then draw the gauge lines, being carefulnot to make any lines beyond the pencil lines.Draw pencil and gauge lines on both top and bot-tom sides. Set the gauge to the line nearest theface edge, and draw all…
