112 ELEMENTARY CABINETWORK … Fig. ioi. Laying out notches under the topic, Finishing Ends, also for the dowel or screw at the top. Draw apencil Hne for the chamfer around the top end.Remove the clamps and draw the knife lines entirely aroundthe bottom ofeach leg; alsocomplete thepencil linesaround the topend for thechamfer.…
