Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 176
e sizes given in the drawing (Fig. 168) are fora light table, which can be taken apart and packedin a trunk. If a more rigid table is desired, theparts may be made heavier. A table of the sizes given in the drawing shouldbe sufficiently rigid for ordinary home drafting. First make the top and… … I70 ELEMENTARY CABINETWORK The cleats should be straight-grained and wellseasoned, and of the same width as the legs. Theends may be beveled and chamfered. Bore holeswith an auger bit to allow the screw heads to sinkabout halfway through the cleats. The hole for theshank of the screw should always…
Cabinetwork
