g offtenons for chairs(Fig. II). Before makingthe lines for theinside ends of thethe tenons ex-amine the shelfcarefully, and if itvaries in size fromthe drawing, cutthe tenons tomatch the shelf.Notice that theshelf is let intothe legs -^ of an Fig. 17 5. Sandpapering edge j^^j^ ^^ ^^^ center of the… … TABLES 179 and measure each way for the width of the tenon.Compare the Hnes as shown in Fig. 8, and if correct,draw gauge Hnes on both edges and ends. Set thegauge so as to draw all the lines from the face side.Compare all the lines before working the tenons. After the tenons have been worked, glue…
