Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 190
cover substantiallyall the information required except that of makingand fitting the drawer. If the legs are to be tapered, the taper shouldnot include the parts which contain the mortisesand the parts against which the rails are fitted. If a drawer is tobe used, the railsare glued togetheras shown… … Fig 180. Rails and drawer runners 184 ELEMENTARY CABINETWORK Be very particular to make this frame square, orthe drawer will not work properly. Read the direc-tions for tapering legs (page 37), for fastening topsto frames (page 96), and also for clamping andfinishing. If the table is to contain a…
Cabinetwork
