Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 213
described under the topic heads Face Marks, Mortises andTenons, Paneling,and Hinges. The sides (Figs.201 and 202a) are sim-ply two pieces ofpaneling with thestiles extended bothabove and below thepanel, and two addi-tional rails. Thesesides may be plannedto have other panelsbetween the lowerand… … Fig. 199. Music cabinet MUSIC CABINET 207 pieces against the side panels (Fig. 201). The panels might have been made thicker and placed flush with the inside of the stiles (Fig. 35). In that case grooves would have been cut in the panel for the shelf ends before the panel was put in place. The…
Cabinetwork
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
