Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 270
remove the door and draw lines with knife, try-square, and Fig. 273. Setting gauge gauge for this side of the hinge, the same as shown in Fig. 272. Remove the waste as before and insert the screws, se-curing the door in place.Sometimes it is better toremove the hinges fromthe first side and fit… … 264 ELEMENTARY CABINETWORK M
Cabinetwork
