Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 272
TOOLS AND MATERIALS 265 … Fig, 277. Butt hinge inposition work is to cut the hole just deep enough. This is usually accomplished by a cut and try method.The surface hinge (Fig. 268) is easily set if you are careful to locate the center of the pin exactly in line with the joint between the door and the frame or case side.…
Cabinetwork
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
