Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 36
ds ofthe mortises, and the pieces adjusted to these marksin clamping the second time. In cases where the mortises are not alike on allsides of the legs (Fig. 122), they may be set on end MORTISES AND TENONS 29 (Fig. 14) in the relative positions they will occupywhen completed, and sketches may be… … Fig. 14. Sketching position of mortises Do not attempt to mark these places exactly.A free-hand sketch indicating the places is all thatis required or necessary, as the pencil marks aresimply to avoid making the mortises on the wrongsides or at the wrong ends. 30 ELEMENTARY CABINETWORK After the…
Cabinetwork
