Elementary course in woodwork ; designed for use in high and technical schools, with one hundred and thirty-four illustrations, by George Alexander Ross (1901)
Ross, George Alexander · Chicago, New York, A. Flanagan Company · leaf 45
Fig. 49. After the block is planed true and to the correctdimensions, lay out the lines across the face at the lefthand end shown in the drawing and square the linesdown the depth on the edges; then set the gauge andmark around the end and notch on both edges. Be-ginners will find it a little… … Fig. 50. 42 ELEMENTARY COURSE IN WOODWORK.
Woodwork (Manual training)
