Elementary course in woodwork ; designed for use in high and technical schools, with one hundred and thirty-four illustrations, by George Alexander Ross (1901)
Ross, George Alexander · Chicago, New York, A. Flanagan Company · leaf 81
ed (the lines being parallel with the edge). Fromthese lines will be drawn the oblique lines across theend with the bevel set at a taper of 1 inch to 4 inches.The bevel can be set by the steel framing square, bythe methods already given. After drawing the lines saw down the required depthon the… … Fig i (The boring is done with the brace, Fig. 103, andthe bit, Fig. 104. Bits are of different forms; Fig. 105shows a number of different styles).
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
