Elementary lectures on electric discharges, waves and impulses, and other transients (1914)
Steinmetz, Charles Proteus, 1865-1923 · New York, London, McGraw-Hill book co., inc. · leaf 68
Fig. 27. — CD5128. — Symmetrical. Momentary Single-phase Short Circuitof Alternator. Oscillogram of Armature Current, Armature Voltage,and Field Current. (Circuit breaker opens.) … Fig. 28. — cd656o. — Asymmetrical. Momentary Single-phase Short Circuitof 5000-Kw. 11,000-Volt Three-phase Alternator (atb-6-5000-500) .Oscillogram of Armature Current and Field Current. Fig. 28 shows the single-phase short circuit of a 6-polar oOOO-kw.11,000-volt steam turbine alternator, which…
Electricity · Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
