, nor is it easy to fix them perfectly parallel to one another.Such an astatic pair is, however,readily deflected by a current flowingin a wire coiled around one of theneedles; for, as shown in Fig. 82,the current which flows above oneneedle and below the other will urgeboth in the same direction,… … the opposite round the lower needle. Nobili applied the astatic arrangement of needles tothe multiplying coils of Schweigger, and thus constructeda very sensitive instrument, the Astatic Galvanoinete7%Shown Ln Fig. 88. The special forms of galvanometeradapted for the measurement of currents are…
