on-sists of an electromagnet round which the line currentflows, and whose delicately poised armature, whenattracted, makes contact for a local circuit in which alocal battery and the receiving Morse instrument areincluded. The principle of the relay is, then, that acun-ent too weak to do the work… … Tig^ 165. a relay. Whenever a current in the line circuit movesthe tongue of the relay it closes the local circuit, andcauses the Morse to record either a dot or a dash uponthe strip of paper. The key K is shown in an. enlarged K
