G. 98.—Force-pump. AB, cylindricalbarrel; BC, suction-pipe ; P, piston ; F,air chamber; V,, valve in suction-pipe ;Vo, valve in outlet pipe; G, dischargepipe ; jR, reservoir from which water istaken. 84 APPLICATiUNiS OF THE LaW.S OF (iA.SES … plunger at each down-stroke through the valve V^ into the dischargepipe. Tlie flow will obviously be intermittent, as the outflow takes placeonly as .the plunger is descending. To produce a continuous stream, andto lessen the shock on the pipe, an air chamber F, is often inserted inthe discharge…
Physics
