Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 276
cylinders of 3V diameter, and 4 stroke; to watercylinders of 20, and steam cylinders of 28 diameter, and 12 stroke.Fig. 9 may be regarded for drawing purposes as a sketch (from a scaledrawing and in true proportion, however) of a pump having a watercylinder of 7, and a steam cylinder of 12…
Geometrical drawing · Mechanical drawing
