one by a verticalplane oblique to V, and one by a plane perpendicular to V andoblique to H. Ex. 13.—Out a regular hexagon from a cube. Ex. 14.—Out a rhombus and an isosceles triangle from thesquare prism. PI. II., Fig. 17. Ex. 15.—Construct the projections of the cylinder, PI. IV.,Fig. 1, after…
