ompassis used in drawing circles andarcs of circles. A complete com-pass outfit (see Fig. 2 2) consists offive parts: (i) the head piece;(2) the needle point; (3) thepencil leg; (4) the pen leg;(5) the extension bar. The instrument may be madeof iron, brass, steel, aluminum,or German silver, the…
