The elements of the mechanics of materials and of power transmission (1911)
King, William Richard, 1852- · New York, J. Wiley & sons; [etc., etc.] · leaf 17
Fig. 6. the whole figure abcde and of fmn respectively. Draw gig2. b … From g2 lay off to scale, in any direction, g2S equal to A\, andparallel to it, and on the same side of gig2, lay off gir. Join 8 THE ELEMENTS OF MECHANICS OF MATERIALS sr and extend it to meet gig2 produced at G. Then the point G is the required center of gravity. The truth of these graphic…
Mechanics, Applied · Power transmission
