The elements of the mechanics of materials and of power transmission (1911)
King, William Richard, 1852- · New York, J. Wiley & sons; [etc., etc.] · leaf 252
edand an exact velocity ratio may be maintained, provided theteeth are carefully constructed on certain geometrical principles. 20. Arrangement of a Train of Toothed Wheels. — An ar-rangement of a train of toothed wheels for the transmission ofpower is shown in Fig. 9, where two wheels of unequal… … Fig. 9. In this arrangement for power transmission the driving wheelsare smaller than the followers, the revolutions of the successive TRANSMISSION BY TOOTHED WHEELS 243 axles decreasing in number. Should a high velocity ratio bethe object desired, the arrangement would be the reverse of thatfor…
Mechanics, Applied · Power transmission
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
