thecoordinate axes, showing an optional notation for the threedimensions of isometric projection and drawing. There is a distinction between isometric projection andisometric drawing, which can be illustrated by the case of PROJECTION. 77 the cube. Fig. 34, B, is an isometric projection of the… … Co-ordin ate Axes. Fig. 35. ing the edges of the cube of a length equal to the true length ofan edge; as, for example, suppose one has a i-inch cube toproject and to draw, the lines of the projection will be .8 inchlong, while the lines of the drawing will be 1 inch long. To illustrate the…
