The elements of natural philosophy : copiously illustrated by familiar experiments and containing descriptions of instruments, with directions for using : designed for the use of schools and academies (1856)

Sprague, A. W. (Alfred White), 1821-1891 · Boston : Phillips, Sampson & Company · leaf 91

An illustration from The elements of natural philosophy : copiously illustrated by familiar experiments and containing descriptions of instruments, with directions for using : designed for the use of schools and academies, 1856, leaf 91
SCREW CONNECTIONS. 85 tween the various parts of a pneumatic apparatus. To these weshall have frequent occasion to refer in the following pages. Fig. 51 Fig. 53. … Figures 51 and 52 are much used for attaching the condenser,hose, etc Fig. 53, small Stop-Cock. Fig. 54, large Stop- 86 SLIDING-RODS. — RUBBER HOSE. Cock. Fig. 55, Connecting-Screw. Fig. 5Q, Guard-Screw.Fig. 57, Screw-Plug. Fig. 58, Gallows-Connector Exterior Fig. 58.
