ogether and all thenegative elements, the current passing through all the cellsat the same moment, the battery is said to be arranged inparallel (Fig. 152). This is analogous to the arrangementof pumps represented in Fig. 153, where only one third ofthe water goes through each pump. Three pumps… … Fig. 152.—Cells in parallel. Fig. 153.—Pumps in parallel. a quantity of water may be supplied to the return pipe asin the former case. The arrangement chosen must dependupon the work to be done, and this will be discussed insection 257. II. Some Effects of Electric Currents 248. Electric Currents…
