Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing (1878)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 40

An illustration from Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing, 1878, leaf 40
Ex. 71. Repeat the divisions of the right angle, given in the 26 FREE-HAND GEOMETRICAL DRAWING. preceding examples, upon right angles in various oblique positions as in Ex, 36. Practical Examples. … Ex. 72. A four pointed star, requiring two lines at rightangles to each other, and the equal bisecting lines of thoseangles.
