Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing (1878)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 44

An illustration from Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing, 1878, leaf 44
■ i; ► 0 O O—i k ik A. AK -A examples obviously require the divisions of lines into equal 30 FREE-HAND GEOMETRICAL DRAWING. parts. Also, in the second figure, the marking of equal dis-tances, viz., the semi-diagonals of the little squares. Ex. 81. Embraces a regular pentagon and some applicationsof…

Geometrical drawing · Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
