Raymond, William Galt, 1859-1926, Raymond, William Galt, 1859-1926. cre · New York, J. Wiley & sons, inc · leaf 112
Fig. 43 88 TURNOUTS … CROSSINGS AND SLIPS 89 for the passage of the street car wheel flanges, and no guardrail is used along the street line rails, but in the heavier cross-ings the guard rails are placed alongside all the rails. Figure 44is suitable for crossings of small angles, say under 18 degrees,and Fig. 45 for…
Railroad engineering
