The areas of the end sections are easily found. It is onlynecessary, in each case, to add together the areas of the trape-zoids composing the whole end figure, as represented in thediagiam, and subtract therefrom the sum of the triangles whichlie outside the section. The dimensions of these… … \2.6 M Now, if a section of this prismoid be taken midway betweenthe two ends, each of its several dimensions must be an arith-metical mean of the corresponding measurements of the endsections. Thus, the centre cutting is found to be 5 ft.; the dis-tance from the angle to slope stake, on the left,…
