RAILROAD STRUCTURES. 1281 valve closed. When taking water, the lever Ji is de-pressed. This causes the short arm k of the lever torise, and lifts the globe/. The weight being thus removedfrom the valve, the disk is lifted by the pressure of thewater which flows through the discharge pipe to the…
