An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed (1836)

Loudon, J. C. (John Claudius), 1783-1843 · London : Longman, Rees, Orme, Brown, Green, & Longmans, and sold by John Weale, at the Architectural Library, High Holborn · leaf 632

An illustration from An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed, 1836, leaf 632 — vat for receiving the Liquor should be placed, ha^•ing a trough from the lip of the press toit. There are three windows, c c c ; the cider-mill, d, is placed in the centre of the house ;and the press, e, at one comer near the door to the vat cellar. Fig. 1171 is a longi- 1171 … tadinal section through the centre of the building, in which maj be seen the cider-mill,n-ith its stone trough, y; upright shaft, g ; grinding wheel, h ; and horse-shaft, i. Fig.1172 is a cross section on the line C D; in which are seen the cider-press, k; the doorto the vat-cellar, I; and the…

Architecture, Domestic · Furniture

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
