Encyclopedia of architecture : a dictionary of the science and practice of architecture, building, carpentry, etc., from the earliest ages to the present time, forming a comprehensive work of reference for the use of architects, builders, carpenters, masons, engineers, students, professional men, and amateurs (1852)

Nicholson, Peter, 1765-1844, Lomax, Edward, Gunyon, Thomas · New York : Johnson, Fry & Co. · leaf 106

An illustration from Encyclopedia of architecture : a dictionary of the science and practice of architecture, building, carpentry, etc., from the earliest ages to the present time, forming a comprehensive work of reference for the use of architects, builders, carpenters, masons, engineers, students, professional men, and amateurs, 1852, leaf 106
pon each of the springing lines,and also upon a middle line between these two lines, set theheights of the winders, and the height of one of the flyersabove and below, or as much as is intended to be taken offthe straight of the rail. Take a pliable slip of wood, straighton one edge, and bend it…

Architecture · Architects
