Engelman's autocraft; being an instructive study of the automobile; its care and management; how to drive; locating troubles and repairing them; with chapters exploiting some of the latest devices used in automobile construction (1914)

Engelman, Roy Albert, b. 1889 · Cincinnati, O., The American chauffeur publishing co. · leaf 51

An illustration from Engelman's autocraft; being an instructive study of the automobile; its care and management; how to drive; locating troubles and repairing them; with chapters exploiting some of the latest devices used in automobile construction, 1914, leaf 51
causing it to break or pull apart from beadto bead. By looking closely you can see how the patchhas pulled away from the position it originallyheld, and has been forced through the break, pro-truding on the outside. (Shown in Fig. 1.) The Care of Tires. 39 BLISTERS CAUSED BY NEGLECTED CUTS. 40… … Fig. 1.BLOWOUT FROM NEGLECTED REPAIRS. Under-Inflation. Under-inflation produces over-heating. Thisin turn saps the life of the fabric in the tire,destroys the cohesion between its various plies, The Care of Tires. 41

Automobiles
