An essay on the history of English church architecture prior to the separation of England from the Roman obedience (1881)
Scott, G. Gilbert (George Gilbert), 1839-1897 · London, Simpkin, Marshall and co. · leaf 271
FIG.TE. Ill FIG.V … KINGS COLLEGE CHAPEL, CAMBRIDGE. FIG. I. CROSS-SECTION OF THE EXISTING BUILDING. FIG. II. CROSS-SECTION AS ORIGINALLY DESIGNED [CONJECTURAL], FIG. III. PLAN OF THE VAULTING SHAFTS. FIG. IV. DIAGRAM OF THE EXISTING FAN-VAULTING. FIG. V. DIAGRAM OF THE VAULTING AS ORIGINALLY DESIGNED [CONJECTURAL].…
Church architecture
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
