The essentials of gearing; a text book for students and for self-instruction, containing numerous problems and practical formulas (1911)
Anthony, Gardner C. (Gardner Chace), 1856- · Boston : D.C. Heath · leaf 47
scribed by roll-ing circles of equal diameter. K P is the addendum, and P L the dedendum of thetooth described by the rolling circles C P, and P D,which are of the same diameter, and equal to one-quarter of the pitch diameter. A C being the ad-dendum line of the engaging gear, C may be consideredas… … Fig. 10. 20 INTERCHAXGEABLE GEARS.
Gearing
