Problem 184 but with axes V2 apart. 186. Find the intersection of a cone and a cylinder (Fig. 294third case). Diameter of cone = IV2. Diameter of cylinder = IV4. Axes intersect. Altitude 2V2. 187. Same as Problem 186 but with axes V2 apart. 188. Find the intersection of a cone and a cyhnder…
