Essentials of Perspective: With Illustrations Drawn by the Author (1887)
Miller, Leslie William, 1848-1931 · New York: C. Scribner's Sons · leaf 48
nd, as can be done easily enough, the squares furnishing a perfectly accurate scale for any part of the picture. The location of the vanishing-point of diagonals never need give you any trouble; whatever looks right for a pretty good-sized square somewhere in the foreground of your picture will be… … Fig. 46. >eyond the edge of your cauvas or paper. MEASUREMENTS OBTAINED BY DIAGONALS. 39 The little diagram at A, in Fig. 47, shows that the vanishing-point of diagonals may he brought asnear as you please without changing the result, if you only reduce the measurement with which you beginin a…
Perspective · Drawing -- Study and teaching
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
