Experimental engineering and manual for testing (1903)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 442
Fig. 164.—Apparatus for Gas Analysis. 432 EXPERIMENTAL EiYGINEERING. [§365. apparatus, shown in Fig. 165, belongs to the class in whicheach reagent is introduced in a concentrated form into a specialtreating-tube. The apparatus consists of a measuring-tubesurrounded by a watCr-jacket, into which… … Fig. 165.—Oksats Gas-analysis Apparatus. reagent is introduced in a concentrated form into a pair ofburettes connected at the bottom by a U-shaped tube. In making an analysis the gas is first drawn into themeasuring-tube and 100 c.c. retained ; the cock in the tubeleading to one of the…
