Experimental engineering and manual for testing (1903)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 618
compression curve on the backstroke can be deducted from the corresponding ordinates of theinertia curve ab^ and the included area shaded, thus exhibitingthe modification of the steam-forces by the inertia of the recip-rocating parts. By vertical measurement of the shaded por-tion, the true… … Fig. 236.—Relatite Motion of Crank-pin and Piston. of the cross-head and crank-pins with crank on its centre,Then, were it not for the angle of the connecting-rod, thecross-head pin would go to p when the crank has moved toc!\ pp being equal to cc. But its true place is at p; thus in the…
