Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 129
Fig. 43.—Draw-head to Olsens Testing-machine. this adjustment is of advantage in some instances in centringthe specimen. For use of the other parts shown in Fig. 43,see Art. 64. The clamps used by Riehle Brothers for holding flat speci-mens are shown in Fig. 44 and Fig. 46, as follows: LOFCX 100…
